Product parameters:
webcam
Image Sensor 1/4 “COMS Image Sensor
Horizontal resolution color 380TV lin; black and white 420TV lin, 40
megapixels
Video format PAL / NTSC auto switch
Resolution 480 * 234
View angle of rotation about 45, 15 is rotated upward, downward rotation of 60
According minimum flow 3Lux / F1.2 (automatically converted dark night care, effective night vision range 5 m)
Transmission signal type motion video and sound in real time
Scanning Frequency PAL / CCIR: 50HZ; NTSC / EIA: 60HZ
Open transmission distance of 300 meters (900 feet), upstairs and downstairs also be transmitted signal
Power Adapter DC5V / 800MA
Transmit power 17dbm
Transmission frequency 2.400GHZ-2.483GHZ
Working temperature -20-60
Body weight 118g
Receiver
Screen Size 3.5 “TFT LCD high-definition LCD screen
Receiver sensitivity + -85dbm
Reception frequency 2.400GHZ-2.483GHZ
Video format PAL / NTSC auto switch
FSK modulation mode
The received signal type motion video and sound in real time
Power Adapter DC5V / 800MA
Operating temperature -10-50
Weight 165g
The number of machines support up to four camera
